Case Study for EV Charging Station Management System
This solution is a robust multitenant SaaS platform for managing EV charging stations.
EV Charging Station Management System
The platform leverages a highly scalable communication architecture and a microservice-based distributed architecture to ensure reliable and efficient operation. The solution implements OCPP standard protocol version 1.6 and Security Profile,
roaming support with OCPI.
The system handles a high
volume of data streams from
IoT devices, processing
information in real-time to
ensure quick response times
and accurate reporting.
OCPP Protocol Stack
The system implements
the OCPP 1.6 and 2.0.1
protocols for
communication between
IoT devices and the server,
enabling seamless
integration with existing
charging infrastructure.
Performance Optimization
The system has been
optimized for performance,
achieving 1-second
response times even with a
large number of charging
stations, ensuring a smooth
and responsive user
experience.a comprehensive view of all aspects of the business.
Scalability of Chargers
The infrastructure has been
designed to scale seamlessly
to handle lakhs of charging
stations, accommodating
future growth and expansion
without compromising
performance.
1. Charging stations communicate with the server system through a secure and reliable network connection, transmitting real-time data about charging status, energy consumption, and other relevant information.
2. The server system utilizes a microservice-based architecture, where individual services handle specific tasks,
such as data processing, user authentication, and payment processing, enabling scalability and flexibility.
3. CPO Role Operations are implemented, with the support to integrate with eMSP.
4. A bulk FW updates helps to reduce the maintenance effort by 40%.
